SCREWING MACHINE

Category: ssv

Specification	CB-LS5441	CB-LS331	CB-LS5441-H	CB-LS6441	CB-LDLS6441-ZS
Operating Range (X)	500 mm	300 mm	500 mm	600 mm	600 mm
Operating Range (Y)	400 mm	300 mm	400 mm	600 mm	400 mm
Operating Range (Z)	100 mm	100 mm	100 mm	100 mm	100 mm
Maximum Moving Speed	colspan: X-axis: 0.1–800 mm/s, Belt Drive: 0.1–400 mm/s
Repeatability Accuracy	colspan: Linear Guide: ±0.02 mm, Belt Drive: ±0.05 mm
Program Memory	colspan: 12 program groups, each containing 100 groups of 40 points
Display	colspan: Touchscreen Display
Motor System	colspan: Japanese Precision Micro-Stepping Motor
Drive System	colspan: Synchronous Belt + Precision Ball Screw + Linear Guide Rail
Input Power	colspan: AC 220V, 50Hz
Operating Air Pressure	colspan: 0.4–0.6 MPa
Communication Interface	colspan: RS-232
Programming Method	colspan: Teach Pendant
Control System	colspan: PLC + Touchscreen Control System
Operating Temperature	colspan: 5°C – 40°C
Operating Humidity	colspan: 20% – 90% RH
Supported Screw Sizes	colspan: M1 – M4
Operating Speed	colspan: 1.0 – 2.5 seconds per screw (varies depending on screw type)
Screw Feeding Method	colspan: Blow Feed / Suction Feed / Magnetic Feed
Dimensions (L × W × H)	650 × 650 × 700 mm	490 × 640 × 660 mm	680 × 750 × 660 mm	700 × 980 × 660 mm	800 × 860 × 1345 mm
Weight	85 kg	60 kg	110 kg	160 kg	180 kg

X, Y, Z represent the machine's working/travel axes.
Repeatability Accuracy refers to how precisely the machine can return to the same position.
Teach Pendant is a handheld controller used to program and operate the machine.
RS-232 is a standard serial communication interface.
MPa stands for megapascal, the unit used for air pressure.
