GLAXY PLUS AUTOMATIC VISUAL SOLDER PASTE PRINTER SPECIFICATION

Print Head & Squeegee System

• Steel or Polyurethane Squeegee Options

• Standard Squeegee Length: 300 mm

• Custom Length Range: 200 mm – 500 mm

• Print Speed: 10 mm/s – 200 mm/s

• Squeegee Pressure: 0 – 20 kg (PID Closed-Loop Control)

• Adjustable Print Gap (Snap-off): 0 – 20 mm

Vision & Alignment System

• Independent Up/Down Looking Vision System

• Camera Field of View: 8 mm × 6 mm

• Alignment Accuracy: ±0.015 mm

• Repetition Accuracy: ±0.010 mm to ±0.020 mm

• Supports Circle, Triangle, Square, Cross Fiducials

• Compatible with Solder Pads and Openings

Stencil Cleaning & Environment Control

• Programmable Dry, Wet & Vacuum Cleaning Modes

• Anti-Static Stick Roller Cleaning System

• Large Vacuum Suction for Efficient Cleaning

• Optional Temperature & Humidity Control

Machine Dimensions & Utilities

• Transfer Height: 900 ± 40 mm

• Power Supply: Single-Phase AC 220V, 50/60Hz

• Air Pressure Requirement: 0.4 – 0.6 MPa

• Designed for High-Precision SMT Production Lines
